Micro VGA Images

See also:

Please click on each image for high resolution version. All images were taken from a live MicroVGA device.

MicroVGA module MicroVGA module - connector view

MicroVGA module connected to host board uVGA on a TFT monitor

uVGA on a CRT monitor uVGA on a 42" plasma television in VGA/RGB mode

uVGA PAL output on a modern LCD TV uVGA PAL output on a really old TV

Color pallette Character set (CP437 / US-ASCII)
